Architectural Double-Hung Window
Architectural Series | Series 463
Treat yourself to this incredible, commercial-grade, Double-hung window, designed with bold frame lines for a premium, elegant finish in even the most exposed environments.
Architectural Series | Series 463
Treat yourself to this incredible, commercial-grade, Double-hung window, designed with bold frame lines for a premium, elegant finish in even the most exposed environments.
Architectural Series | Series 463
Treat yourself to this incredible, commercial-grade, Double-hung window, designed with bold frame lines for a premium, elegant finish in even the most exposed environments.
Technical Information
Thick, strong sashes can handle very large glass spans, for brilliant views and interior comfort even in high wind areas.
The perimeter frame has been designed to make installation into brick veneer and cavity brick easier, plus both sashes can hinge back into the room for easy cleaning of both sides of the glass, without removing the fly screen!
Windows can be secured with a custom key or non-key locking cam handle.
Tested for compliance and drainage at 450Pa water resistance, so they’re ideal for any location in Australia.
*Maximum Frame Height and Panel Widths indicated are interdependent and subject to individual site conditions.
Maximum Frame Height* 1050mm
Maximum Panel Width * 1155mm
Maximum Glass Thickness ≤ 20mm
SHGC Range 0.2 - 0.58
Uw Range 3.6 - 6.5
